Abrasive Wheels
As an essential tool in industrial production, abrasive wheels can perform tasks such as cutting, grinding, and polishing. As a manufacturer of high-quality resin grinding wheels, Dome’s main types of abrasive discs include cutting wheels, grinding wheels, flap discs, and ceramic grinding discs. Dome Abrasive Manufacture can provide you with tailor-made abrasive wheels to help maximize your production efficiency. Dome has been deeply involved in the grinding abrasive disc industry for 26 years, serving customers all over the world, such as Truper, Vonder, Uyustools, DeWalt, Stanley, etc.
What is a Cutting Wheel?
Cutting wheels a thin piece used for cutting metal materials such as steel, stainless steel, and alloy steel. Its outer diameter is usually 38mm-405mm, and its thickness is 0.8mm-3.2mm. Made of high-strength fiberglass mesh and zirconium-plated white corundum, it has strong cutting performance, high precision, and is resistant to breakage and wear. It is widely used in the metal processing industry, manufacturing industry, shipyard and other fields.
What is a Grinding Wheel?
Grinding wheels are discs used for grinding metal surfaces, removing burrs, cleaning weld scars, and finishing carbide tools. Its outer diameter is usually 50mm-230mm, thickness 3mm-7mm, general thickness 6mm, cymbal type (T27) structure. Made of abrasives with good self-sharpening and high strength, slightly thicker and with high grinding finish, the workpiece should not be burned. Suitable for steel plants, shipbuilding industry, automobile manufacturing and other fields.
What is a Ceramic Grinding Disc?
Ceramic grinding disc is a grinding disc that can quickly grind welds, remove burrs, and treat stainless steel surfaces. Made of high-performance ceramic abrasives, it has stronger self-sharpening and longer service life than ordinary grinding discs. Used in shipbuilding, aerospace, railway maintenance, etc.
What is a Flap Disc?
The flap disc is used for surface treatment such as grinding and polishing, rust removal, and paint removal of carbon steel, stainless steel and other metal materials. The product consists of two parts. The base body is usually a nylon cover or a fiberglass mesh cover, and the main body is abrasive cloth or sandpaper of different mesh numbers and materials. The product is lightweight, has many options, has the characteristics of good heat dissipation and high grinding efficiency. It is widely used in mechanical processing, bridge and construction industries, furniture manufacturing and other fields.
Dome Provides Cutting-edge Grinding Wheel Customization
Dome Abrasive Manufacture supports customization of abrasive disc size, thickness, abrasives and packaging solutions. Dome has extensive experience in customizing abrasive discs. In addition to regular customization needs, Dome also provide customization of abrasive discs with special sizes and special requirements. Dome Abrasive Manufacture offers competitive abrasive disc prices and accepts mixed models, trial orders, and bulk shipments. Dome’s abrasive wheels have passed the German MPA certification and meet the safety requirements of European EN12413 bonded abrasives.
- 1vs1 service, providing long-term abrasive disc customization planning for your brand.
- Enjoy factory direct pricing, saving over 20% on retail prices.
- No contaminants (Fe + Cl + S < 0.1%), each abrasive disc complies with EU import regulations.
- Reduces cutting dust by 30%.
- Customized abrasive discs of different grades. Compared with abrasive discs of the same grade, our cutting efficiency is increased by 30% and the service life is extended by 50%.
- Multi-layer fiber mesh reinforcement technology, 50% improvement compared to single-mesh structures.
- Utilizes automatic pressing and constant temperature curing process, with a thickness tolerance of ±0.1mm.
One-stop Customization for Your Exclusive Abrasive Wheels
Dome Abrasive Manufacture offers a range of abrasive disc products, including cutting wheels, grinding wheels, and flap discs, widely used in various industries. Dome provide product selection guidance, price comparison support, and application advice to help you choose the most cost-effective abrasive wheel solution.
Cutting Wheels
Applicable Tools: Angle grinder
Applicable Materials: Steel and cast steel, alloy/cast steel, tool steel, cast iron, aluminum, stainless steel
Technical Specifications:
| Dimension D*T*A(mm) | Dimension D*T*A(inch) | Shape | Max Speed (m/s) | Max RPM |
|---|---|---|---|---|
| 50×1.0x10 | 2×1/24×3/8 | T41 | 80 | 20100 |
| 58×1.0x10 | 2×1/24×3/8 | T41 | 80 | 20100 |
| 75×0.8×10 | 3×1/32×3/8 | T41 | 80 | 20100 |
| 75×1.0/1.2×10 | 3×1/24×3/8 | T41 | 80 | 20100 |
| 75×1.6×10 | 3×1/16×3/8 | T41 | 80 | 20100 |
| 100×2.0x16 | 4×1/12×5/8 | T41 | 80 | 15200 |
| 100×3.0x16 | 4×1/8×5/8 | T41 | 80 | 15200 |
| 105/107×1.0x16 | 4×1/25×5/8 | T41 | 80 | 15200 |
| 105/107×1.2×16 | 4×3/64×5/8 | T41 | 80 | 15200 |
| 105/107×1.6×16 | 4×1/16×5/8 | T41 | 80 | 15200 |
| 115×1.0x22.2 | 4 1/2×1/25×7/8 | T41 | 80 | 13300 |
| 115×1.2×22.2 | 4 1/2×3/64×7/8 | T41 | 80 | 13300 |
| 115×1.6×22.2 | 4 1/2×1/16×7/8 | T41 | 80 | 13300 |
| 115×2.0x22.2 | 4 1/2×1/12×7/8 | T41 | 80 | 13300 |
| 115×3.0x22.2 | 4 1/2×1/8×7/8 | T41 | 80 | 13300 |
| 125×1.0x22.2 | 5×1/25×7/8 | T41 | 80 | 12200 |
| 125×1.2×16 | 5×3/64×5/8 | T41 | 80 | 12200 |
| 125×1.2×22.2 | 5×3/64×7/8 | T41 | 80 | 12200 |
| 125×1.6×22.2 | 5×1/16×7/8 | T41 | 80 | 12200 |
| 125×2.5×22.2 | 5×3/32×7/8 | T41/T42 | 80 | 12200 |
| 125×3.0x22.2 | 5×1/8×7/8 | T41/T42 | 80 | 12200 |
| 150×1.6×22.2 | 6×1/16×7/8 | T41 | 80 | 10200 |
| 150×2.0x22.2 | 6×1/12×7/8 | T41 | 80 | 10200 |
| 150×3.0x22.2 | 6×1/8×7/8 | T41 | 80 | 10200 |
| 180×1.6×22.2 | 7×1/16×7/8 | T41 | 80 | 8500 |
| 180×2.0x22.2 | 7×1/12×7/8 | T41 | 80 | 8500 |
| 180×3.0x22.2 | 7×1/8×7/8 | T41 | 80 | 8500 |
| 230×1.6×22.2 | 9×1/16×7/8 | T41 | 80 | 6600 |
| 230×2.0x22.2 | 9×1/12×7/8 | T41 | 80 | 6600 |
| 230×3.0x22.2 | 9×1/8×7/8 | T41/T42 | 80 | 6600 |
| 250×2.5×25.4 | 10×3/32×1 | T41 | 80 | 6150 |
| 250×3.0x25.4 | 10×1/8×1 | T41 | 80 | 6150 |
| 305×2.0x25.4 | 12×1/12×1 | T41 | 80 | 5100 |
| 305×2.5×25.4 | 12×3/32×1 | T41 | 80 | 5100 |
| 305×3.0/3.2×25.4 | 12×1/8×1 | T41 | 80 | 5100 |
| 305×3.5×25.4 | 12×9/64×1 | T41 | 80 | 5100 |
| 305×3.8×25.4 | 12×5/32×1 | T41 | 80 | 5100 |
| 355×2.0x25.4 | 14×1/12×1 | T41 | 80 | 4400 |
| 355×2.5×25.4 | 14×3/32×1 | T41 | 80 | 4400 |
| 355×3.0/3.2×25.4 | 14×1/8×1 | T41 | 80 | 4400 |
| 355×3.5×25.4 | 14×9/64×1 | T41 | 80 | 4400 |
| 355×4.0x25.4(Rail) | 14×5/32×1 | T41 | 80 | 4400 |
| 405×3.0/3.2×32 | 16×1/8×5/4 | T41 | 80 | 3800 |
| 405×3.5×32 | 16×9/64×5/4 | T41 | 80 | 3800 |
| 405×3.8×32 | 16×5/32×5/4 | T41 | 80 | 3800 |
| 405×4.0x32 | 16×5/32×5/4 | T41 | 80 | 3800 |
Grinding Wheels
Applicable Tools: Angle grinder, cutting machine
Applicable Materials: Ordinary steel, stainless steel, aluminum, cast iron, alloy steel, etc.
Technical Specifications:
| Dimension D*T*A(mm) | Dimension D*T*A(inch) | Shape | Max Speed (m/s) | Max RPM |
|---|---|---|---|---|
| 50×4.0x10 | 2×5/32×3/8 | T27 | 72/80 | 20100 |
| 58×4.0x10 | 2×2/32×3/8 | T27 | 72/80 | 20100 |
| 76×4.0x10 | 3×5/32×3/8 | T27 | 72/80 | 20100 |
| 100×4.0x16 | 4×5/32×5/8 | T27 | 72/80 | 15200 |
| 100×6.0x16 | 4×1/4×5/8 | T27 | 72/80 | 15200 |
| 100×8.0x16 | 4×5/16×5/8 | T27 | 72/80 | 15200 |
| 115×6.0x22.2 | 4 1/2×1/4×7/8 | T27 | 72/80 | 13300 |
| 125×6.0x22.2 | 5×1/4×7/8 | T27 | 72/80 | 12200 |
| 150×6.0x22.2 | 6×1/4×7/8 | T27 | 72/80 | 10200 |
| 180×6.0x22.2 | 7×1/4×7/8 | T27 | 72/80 | 8500 |
| 230×6.0x22.2 | 9×1/4×7/8 | T27 | 72/80 | 6600 |
Ceramic Grinding Discs
Applicable Tools: Angle grinder, grinding machine
Applicable Materials: Stainless steel, steel/carbon steel, aluminum alloy
Technical Specifications:
| Dimension D*T*A(mm) | Dimension D*T*A(inch) | Shape | Max Speed (m/s) | Max RPM |
|---|---|---|---|---|
| 100×16 | 4×5/8 | T29 | 80 | 15200 |
| 115×22 | 4 1/2×7/8 | T29 | 80 | 13300 |
| 125×22 | 5×7/8 | T29 | 80 | 12200 |
Flap Discs
Applicable Tools: Angle grinder, grinding machine
Applicable Materials: Stainless steel, carbon steel, alloy steel, aluminum
Technical Specifications:
| Dimension D*T*A(mm) | Dimension D*T*A(inch) | Shape | Max Speed (m/s) | Max RPM | Grit Size(#) |
|---|---|---|---|---|---|
| 58×10 | 2×3/8 | T27/T29 | 80 | 15200 | 40/60/80/120 |
| 75×10 | 3×3/8 | T27/T29 | 80 | 13300 | 40/60/80/120 |
| 100×16 | 4×5/8 | T27/T29 | 80 | 15200 | 40/60/80/120 |
| 115×22 | 4 1/2×7/8 | T27/T29 | 80 | 13300 | 40/60/80/120 |
| 125×22 | 5×7/8 | T27/T29 | 80 | 12200 | 40/60/80/120 |
| 180×22 | 7×7/8 | T27/T29 | 80 | 8500 | 40/60/80/120 |
From Sample to Mass Production, Dome is Responsible for the Entire Process
Say Goodbye to General Solutions and Get Exclusive Abrasive Wheel OEM Solutions
Beyond the Visible: Redefining Abrasive Wheel Standards
Dome Abrasive Manufacture provides high-quality abrasice wheels that fit your budget, partnering with leading abrasive wheel suppliers to help you succeed in this industry. Revolutionize your product line and enhance your reputation for reliability with Dome’s premium abrasive wheel.
Superior Raw Materials
Each batch of raw materials undergoes multiple tests such as ball grinding toughness to ensure the performance and cost-effectiveness of the abrasive wheels.
Precisely Matched Abrasives
Dome Abrasive Manufacture designs the optimal formula based on your abrasive wheel application scenarios, precisely matching customer needs.
Innovative Structural Design
Double network enhanced design, the mesh is selected according to the model. The tensile strength reaches 285Mpa, which greatly reduces the risk of breakage.
Quality and Performance
The abrasive wheels have a flatness tolerance of less than 0.02mm, excellent toughness, and high density, making them suitable for a variety of applications.
Precise Delivery Time
With over 60 automated production lines and strong production planning capabilities, Dome Abrasive Manufacture offer a standard order delivery cycle of 35 days.
Safety Assurance
Dome Abrasive Manufacture exported abrasive wheels meet the safety standards of other countries, and all abrasive discs are covered by PICC quality insurance.
Dome-the Benchmark Factory in China’s Abrasive Wheel Industry
Dome Abrasive Manufacture refuses to provide you with general formulas. Instead, Dome individually designs and debug abrasive formulas based on your specifications, materials, and usage scenarios to ensure that the abrasvie wheel performance meets your needs. Dome helps you accurately control procurement costs and win the market.
R&D Strength, Patent Support
As a national high-tech enterprise, Dome Abrasive Manufacture has 20+ invention patents for abrasive wheels and abrasives, and is equipped with 10+ dedicated R&D personnel.
Large-scale Production, Stable Delivery
Dome Abrasive Manufacture has a 20,000+m² modern production workshop that supports customization of various abrasive wheel sizes, with a daily output of 600,000 pieces.
Strict Control Over the Entire Chain, Quality Traceability
From raw material preparation, molding to firing, the entire production process is precisely controlled to ensure that each abrasive wheel has consistent performance, safety and reliability.
Global Trust, Strength Certification
80% of Dome Abrasive Manufacture’s annual output is exported to Europe, Southeast Asia, South America, Africa and other places. The abrasive wheels meet the standards of many countries and the quality is recognized by the global market.
A Trustworthy OEM Manufacturing Partner
Strict Quality Control and Efficient Production Capacity Ensure A Stable Supply of Your Abrasive Wheels.
Witness the Production Process of Your Brand’s Abrasive Wheel
Welcome to the production workshop of our factory. Here, Dome Abrasive Manufacture will work together to prepare the formula, press molding, precision sintering, and final balance calibration for you. Witness how your exclusive abrasive wheel transforms from raw material abrasive into a complete abrasive wheel.
Customer Feedback
FAQ
Q1: Are you a trading company or an abrasive disc manufacturer?
A: We are an abrasive wheel manufacturer, Dome Abrasives Manufacture is a leading Chinese manufacturer of resin-bonded abrasive discs, integrating development, design, production, sales, and service. Our factory is located in Changzhou City, Jiangsu Province, near Shanghai.
Q2: Do you provide OEM and ODM customization services? What specific aspects do they include?
A: Yes. Dome Abrasive Manufacture offers a wide range of grit sizes, hardness grades, and abrasive materials to ensure that the price of the abrasive wheel reflects its actual performance value. Dome provides free design services for your product logo, labels, and packaging. Simply provide your specific requirements, and Dome will tailor a solution for you.
Q3: Is there a minimum order quantity for OEM custom abrasive discs?
A: Yes.
The minimum order quantity for small-sized abrasive discs (2-inch, 3-inch, 4-inch) is 10,000 pieces.
The minimum order quantity for medium and large-sized abrasive discs is 5,000 pieces.
Q4: How do I choose the right abrasive disc based on my processing materials (such as carbon steel, stainless steel) and processes?
A: Dome Abrasive Manufacture will develop abrasives based on your material type, specific machine speed, and usage intensity to ensure the abrasive wheel meets your requirements. Dome also provides samples for testing, and only proceed with mass production after successful testing.
Q5: What is the typical delivery time for a custom-made abrasive wheel?
A: The normal delivery time for a custom-made abrasive wheel is approximately 30 days. The delivery time for non-standard custom orders depends on the project plan.
Q6: Can we provide samples or drawings for customization? Do you provide test samples?
A: Yes. The samples or drawings you provide will shorten the abrasive development cycle, allowing Dome Abrasive Manufacture to develop even better abrasive wheels. Dome will provide free test samples for your abrasive wheel project and guarantee that the performance of the mass-produced abrasive discs will be consistent with the samples.
Q7: How to ensure the quality, performance consistency, and safety of OEM abrasive wheels?
A: A traceable raw material supply chain. Mature production processes support the continuous production of abrasive wheels. A constant temperature and humidity production environment ensures product precision and quality. The quality inspection team conducts a comprehensive review of the entire production process, and finished products undergo multiple sample tests. Dome adheres to the ISO 9001 quality management system, ensuring that products meet standards before shipment.
Q8: How can the packaging and brand identification of custom-made abrasive wheels be handled?
A: Abrasive disc packaging options:
Inner packaging: Vacuum sealing, plastic containers, white boxes, tin boxes, kraft paper boxes, etc.
Outer packaging: Kraft paper cartons, colored cardboard boxes, etc.
Brand identification printing methods: Offset printing, flexographic printing, screen printing.
Q9: Facing the demand for high-efficiency and high-precision machining in industries such as shipbuilding, rail cutting, and automobile manufacturing, what advantages do your customized abrasive wheel solutions offer?
A: The Dome Abrasive Manufacture technical team will develop abrasive discs that meet your needs based on your processing materials, tool specifications, and desired processing results. Dome helps you choose the most cost-effective abrasive disc solution. Dome Abrasive Manufacture guarantees a stable supply of large quantities, supporting the smooth operation of your business.
Q10: Against the backdrop of environmental protection and automated production becoming trends, what are the characteristics of your abrasive wheels in terms of environmental performance and production processes?
A: Dome Abrasive Manufacture’s factory adheres to the ISO 14001 environmental management system and actively uses environmentally friendly packaging materials to help customers meet export environmental requirements. The core production lines are equipped with automatic batching systems, automated production lines, and intelligent inspection machines. From raw material warehousing to finished product shipment, all processes are recorded, providing customers with transparent quality traceability.
Help You Expand Global Markets
Meet Strict Environmental Protection and Performance Requirements, Professional Abrasive Wheel OEM Customization.
Certificate
Dome Abrasive Manufacture’s abrasive wheels have obtained a number of important international certifications, including CE, MPA and BSCI. This achievement demonstrates Dome’s strong commitment to the highest standards of product safety, grinding performance and social responsibility.
Focus on Export Market
As an export-focused abrasive wheel manufacturer, Dome Abrasive Manufacture is well versed in global quality and compliance standards. Dome provides you with abrasive wheel solutions that match the local market and customer groups to maximize your business efficiency.
Latin America
Mainstream Models:
115×1.0x22.2mm
115×3.0x22.2mm
115×6.0x22.2mm
180×1.6×22.2mm
230×2.0x22.2mm
355×3.0x25.4mm
Europe
Mainstream Models:
115×1.0x22.2mm
125×1.0x22.2mm
125×6.0x22.2mm
150×1.6×22.2mm
180×1.2×22.2mm
230×2.0x22.2mm
Africa
Mainstream Models:
115×1.0x22.2mm
180×6.0x22.2mm
230×2.0x22.2mm
Asia
Mainstream Models:
100×6.0x16mm
107×1.0x16mm
355×2.5×25.4mm
355×3.0x25.4mm
Small Batch, Truly Customized
Flexible OEM Model, Dome’s Exclusive Production Line for Your Abrasive Wheels.
Start Small, Scale Smart: Your Custom OEM Journey Begins Here
Dome Abrasive Manufacture provides 10 free samples for qualified projects for you to measure performance, experience quality, and verify specifications. If you’re ready to turn your vision into reality, contact us today to discuss a project and pick up samples.
